Wires / Cable Pinout:

* Blue - 3.3V Supply (Required)
Yellow - 5V Supply (used for rumble only)
* Red - Send/Receive (Required)
* Green - Ground for 3.3V (Required)
White - Ground for 5V (used for rumble only)
Black - Tie-in for cable shielding
